The parameter of CUTCNC[CUTCNC?:cutting machine sample maker manufacturer] package sample cutting plotter:
Effective cutting area(mm) 1300*1000
configuration oscillating blade, pen, creasing wheel, servo motor
function it is used in carton[carton?:carton box sample cutting machine]&paper[paper?:paper sample maker cutting machine] box packing factory, it can cut and crease 15mm corrugated paper[corrugated paper?:DCP-H series sample cutter plotter]
max speed 1000mm/s
smallest cutting diameter 6mm
maximum cutting thickness 15mm
control line and driver servo
overlapping precision Less than or equal 0.1mm
vacum 5.5KW
data form HPGL
voltage 220V Plus or minus10% 50Hz
data port PCI port
data transmission speed 10MB/S
Using dimension (mm) 1960*1890*1150
Input cushion area 32MB
CUTCNC package sample cutting plotter can be wildly used to make samples and do short run productions of package.
